Multi-lane Bag Making Machine

SS6-V
SS4-V
FEATURES :
  • Seal bar can be easily changed for shopping bags and plain bags.
  • Electronic clutch and brake ensure accurate bag cutting and sealing, deviation within 1mm.
  • Servo type system ensures accurate bag cutting and sealing, deviation within 0.5mm.
  • Sensor controls input of film rolls, assuring perfect sealing line without tension.
  • Automatically stops if film is empty or stuck.
  • Print sensors guarantee the precision of the printed bags.
SPECIFICATIONS :
Model Bag Size (Max.)
linexlayerxWxL(mm)		 Thickness
of film(mm)		 Capacity
(cycle/min.)		 Power Required Machine Size
LxWxH(M)
SERVO TYPE SS4-700V 1x2x680x1200
2x2x305x1200		 0.008~0.15 30~160x4 7.6KW 4.25X1.55X1.99
SS4-800V 1x2x780x1200
2x2x355x1200		 0.008~0.15 30~160x4 8KW 4.25X1.65X1.99
SS4-1000V 1x2x980x1200
2x2x455x1200		 0.008~0.15 30~160x4 9.5KW 4.25X1.85X1.99
SS6-800V 1x2x780x1200
2x2x355x1200
3x2x220x1200		 0.008~0.15 30~160x6 8.8KW 4.41X1.65X1.99
SS6-1000V 1x2x980x1200
2x2x455x1200
3x2x320x1200		 0.008~0.15 30~160x6 10.3KW 4.41X1.85X1.99
CLUTCH & BRAKE TYPE SS4-700 1x2x680x1010
2x2x305x1010		 0.008~0.15 30~110x4 6.2KW 4.25X1.55X1.99
SS4-800 1x2x780x1010
2x2x355x1010		 0.008~0.15 30~110x4 6.6KW 4.25X1.65X1.99
SS4-1000 1x2x980x1010
2x2x455x1010		 0.008~0.15 30~105x4 6.8KW 4.25X1.85X1.99
SS6-800 1x2x780x1010
2x2x355x1010
3x2x220x1010		 0.008~0.15 30~110x6 7.5KW 4.41X1.65X1.99
SS6-1000 1x2x980x1010
2x2x455x1010
3x2x320x1010		 0.008~0.15 30~105x6 7.7KW 4.41X1.85X1.99
  • Design and specifications are subject to change without prior notice
