6 COLOR FLEXOGRAPHIC PRINTING MACHINE
Printing Machine
SPECIFICATIONS :
Description\Printing with(mm) 500 800 1000
Color printed 6
Printing speed (max.)(M/min.) 60
Film passing width (max.)(mm) 600 900 1100
Printing length (mm) 200-800
Printing possibility 0+6, 1+5, 2+4, 3+3
Main motor (HP) 5 7 1/2 7 1/2
Heater (KW) 1.5 X 13 1.5 X16 1.5 X 19
Blower for heater (HP) 1/2 HP X1 , 5HP X 1 1/2 HP X1 , 7 1/2 HP X 1
Hydraulic pump motor (HP) 1
Lnk roll motor (HP) 1/2
Torque motor (kg) 30 X 2 50 X 2
Total Power(KW) 22 25 28

Printing width
(mm)
Length
(cm)
Width
(cm)
Hieght
(cm)
Net weight
(kg)
Gross weight (kg) Loading Volunie
(cm)
500 420 190 270 4200 5000
800 420 216 270 4500 5300 457x220x230
1000 420 236 270 5000 5800
  • Design and specifications are subject to change without prior notice
